38kg/H Hydrolyzed Fish Protein Fish Drying Equipment Industrial Dehydrator Machine

38kg/H Hydrolyzed Fish Protein Fish Drying Equipment Industrial Dehydrator Machine Hydrolyzed fish protein solution spray dryer Ⅰ.Conditions of design 1. Material Conditions Raw material: Hydrolyzed fish protein solution Initial water content: 85% Final water content: ≤3.5% Capacity: 38 kg/h Liquid Temp: ambient temperature 2. Technology Conditions Atomizing type: centrifugal The way of the drops and hot air contact: co-current flow Heat source and the way of heating: LPG Natural gas hot air furnace Inlet temperature: 200℃ Outlet temperature: About 80℃ Product collecting: Main tower + cyclone 3. Atmosphere Conditions Atmospheric pressure: 101.325KPa Ambient Temp: 20℃ Relative Humidity: 80% 4. Public Facilities 4.1 Electric power Electric power: 380V, 50HZ, 3phase, Power: 45 Kw 4.2 .Compressed air Pressure: 0.6 MPa Consumption: 0.6m3 /min 4.3 Water Consumption: for cleaning 4.4 Field to be installed (L× W× H)m Length×Width×Height 8×8×11 Ⅱ. System description Primary Model Selection: LPG-250 Model Spray Dryer (38kg/h capacity) Heating way:LPG Natural Gas Hot Air Furnace Dust collecting system:cyclone Circulatory system: Blast & suction fan opened Air - filtering system: Initial, Middle level air filter Feed System: High-pressure pump adjustable feeding (suggest 2 sets, one for reservation after commission) Controlling system: Digital meter show the temperature, pressure, differential pressure, Touch screen show the working flow, PLC controlling parameters etc. Ⅲ. Scope of Application 1. Spray dryer system consisted of the following (1). Inlet system (2). Hot air system (3). Drying system (4). Duster system (5). Air exhaust system (6). Control system Technical Parameters Evaporated amount of moisture 210Kg/h(max) Diameter and height of tower 4.0M/9.0M Operation temperature inlet200/outlet80 Atomizing plate Φ150 Install power drive~42KW Air quantity 5000Kg/h Heat quantity 35×104Kcal/h Recycle water consumption 500Kg/h Compressed air consumption(0.6Mpa) 0.6m3/min       Type of drying system Open circulation Way of material feeding Single-screw pump steady feeding Way of hot air connecting co-current flow Way of heating LPG Hot Air Furnace Way of product collecting dry tower +cyclone Way of atomizing centrifugal atomizing Way of control Automatic controlling the inlet temperature, Digital meter show the temperature, pressure, differential pressure, Touch screen show the working flow, PLC controlling parameters etc.

2023

08/04

1
