Changzhou Shinma Drying Engineering Co.,LTD.
About Us
Your Professional & Reliable Partner.
Changzhou Shinma Drying Engineering Co.,LTD, in jintan district,changzhou city of Jiangsu, which is in the middle of Shanghai-Nanjing Express way. Company has 2 large modern construction machinery manufacturing plants, equipped with whole line of sheet metal bending, laser cutting, automatic polishing, automatic welding, occupies an area of 500,000 square meters. Also we have our own R&D team, which has a number of talents and individual test lab.We are specializing in researching and developing ...
Learn More

0

Year Established

0

Million+
Employees

0

Million+
Annual Sales
China Changzhou Shinma Drying Engineering Co.,LTD. HIGH QUALITY
Trust Seal, Credit Check, RoSH and Supplier Capability Assessment. company has strictly quality control system and professional test lab.
China Changzhou Shinma Drying Engineering Co.,LTD. DEVELOPMENT
Internal professional design team and advanced machinery workshop. We can cooperate to develop the products you need.
China Changzhou Shinma Drying Engineering Co.,LTD. MANUFACTURING
Advanced automatic machines, strictly process control system. We can manufacture all the Electrical terminals beyond your demand.
China Changzhou Shinma Drying Engineering Co.,LTD. 100% SERVICE
Bulk and customized small packaging, FOB, CIF, DDU and DDP. Let us help you find the best solution for all your concerns.

quality Spray Dryer Machine & Centrifugal Spray Dryer manufacturer

Find Products That Better Meet Your Requirements.
Cases & News
The Latest Hot Spots.
LPG-500 Beer Yeast Spray Dryer spray drying equipment
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V   LPG-500 Beer Yeast Spray Dryer spray drying equipment Equipment design condition 1, Liquid conditions Liquid product name: beer yeast liquid Initial moisture: ~85% (design as 80%) Final Moisture: ≤5% Water evaporation capacity 500kg/h The liquid temperature: Ambient temperature 2, Processing conditions Spray method: Centrifugal atomizer Liquid and the hot air contacting method: Co-current Heat source and heating: Electric heating Inlet temperature: 180~200℃(design as 180℃) Exhaust temperature: 90~100℃(design as 85℃) Product Capture mode: Cyclone separator + wet scrubber Product collect mode: Frozen dehumidification product collect 3, the design weather conditions ( Standard ) Atmospheric pressure 101.3KPa Environment temperature: 10 ℃ Relative Humidity: 80% 4, Public Works 4.1, Power Power supply: 380V, 3 phase, 50HZ Power: Drive 96.5kw + electric heating 1125kw + air sweeper electric heating 18kw 4.2, Compressed air Pressure: 0.6 MPa Consumption: 1.5m3/min 4.3, Water Pressure: Cleaning water gun Consumption: 1000kg/h 4.3, equipment covers an area space L × W × H 16m × 12m × 16m Technical data sheet Water Evaporation 500kg/h (pure water) Diameter/Height 5.6M/13.5M Operation temp In 180℃-200℃ / Out 90-100℃ Atomizer LPG-500 Rolling speed 15500 rpm Diameter 150mm Electricity Power Drive 80kw Heat supply About 5.81 x105 kcal/h Hot water consumption 1000kg/time (for cleaning) Electric consumption 770-880 kilowatt-hour   Drying type Open circle system Feeding type Screw pump Hot air way Co current Heat source Electric Dust system Cyclone separator + wet scrubber Atomizer way Centrifugal atomizer
38kg/H Hydrolyzed Fish Protein Fish Drying Equipment Industrial Dehydrator Machine
38kg/H Hydrolyzed Fish Protein Fish Drying Equipment Industrial Dehydrator Machine Hydrolyzed fish protein solution spray dryer Ⅰ.Conditions of design 1. Material Conditions Raw material: Hydrolyzed fish protein solution Initial water content: 85% Final water content: ≤3.5% Capacity: 38 kg/h Liquid Temp: ambient temperature 2. Technology Conditions Atomizing type: centrifugal The way of the drops and hot air contact: co-current flow Heat source and the way of heating: LPG Natural gas hot air furnace Inlet temperature: 200℃ Outlet temperature: About 80℃ Product collecting: Main tower + cyclone 3. Atmosphere Conditions Atmospheric pressure: 101.325KPa Ambient Temp: 20℃ Relative Humidity: 80% 4. Public Facilities 4.1 Electric power Electric power: 380V, 50HZ, 3phase, Power: 45 Kw 4.2 .Compressed air Pressure: 0.6 MPa Consumption: 0.6m3 /min 4.3 Water Consumption: for cleaning 4.4 Field to be installed (L× W× H)m Length×Width×Height 8×8×11 Ⅱ. System description Primary Model Selection: LPG-250 Model Spray Dryer (38kg/h capacity) Heating way:LPG Natural Gas Hot Air Furnace Dust collecting system:cyclone Circulatory system: Blast & suction fan opened Air - filtering system: Initial, Middle level air filter Feed System: High-pressure pump adjustable feeding (suggest 2 sets, one for reservation after commission) Controlling system: Digital meter show the temperature, pressure, differential pressure, Touch screen show the working flow, PLC controlling parameters etc. Ⅲ. Scope of Application 1. Spray dryer system consisted of the following (1). Inlet system (2). Hot air system (3). Drying system (4). Duster system (5). Air exhaust system (6). Control system Technical Parameters Evaporated amount of moisture 210Kg/h(max) Diameter and height of tower 4.0M/9.0M Operation temperature inlet200/outlet80 Atomizing plate Φ150 Install power drive~42KW Air quantity 5000Kg/h Heat quantity 35×104Kcal/h Recycle water consumption 500Kg/h Compressed air consumption(0.6Mpa) 0.6m3/min       Type of drying system Open circulation Way of material feeding Single-screw pump steady feeding Way of hot air connecting co-current flow Way of heating LPG Hot Air Furnace Way of product collecting dry tower +cyclone Way of atomizing centrifugal atomizing Way of control Automatic controlling the inlet temperature, Digital meter show the temperature, pressure, differential pressure, Touch screen show the working flow, PLC controlling parameters etc.
