ISO9001 SUS304 Flour Drying Machine Multifunctional Cassava Dryer Machine

Name: ISO9001 SUS304 Flour Drying Machine Multifunctional Cassava Dryer Machine
Brand: shinma
SKU: XSG-6
Price: 30000 USD
Availability: InStock
Rating: 4.9 (116 reviews)

Product Details

Place of Origin: changzhou

Brand Name: shinma

Certification: ISO9001,ISO14001

Model Number: XSG-6

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: USD30000-100000/set

Packaging Details: nacked packing

Delivery Time: 60days

Payment Terms: L/C, D/A, D/P, T/T

Supply Ability: 20sets

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                ISO9001 flour drying machine, SUS304 flour drying machine, Multifunctional cassava dryer machine


Application:	Chemicals Processing, Plastics Processing, Food Processing	Condition:	New
Key Selling Points:	Multifunctional	Applicable Industries:	Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Food Shop, Food & Beverage Shops, Other
Voltage:	220v/380v/Customer Request	Material:	SUS304
Certificate:	CE,ISO	Type:	Flash Drying Equipment
Name:	Spin Flash Dryer

Application:	Chemicals Processing, Plastics Processing, Food Processing
Condition:	New
Key Selling Points:	Multifunctional
Applicable Industries:	Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Food Shop, Food & Beverage Shops, Other
Voltage:	220v/380v/Customer Request
Material:	SUS304
Certificate:	CE,ISO
Type:	Flash Drying Equipment
Name:	Spin Flash Dryer

ISO9001 SUS304 Flour Drying Machine Multifunctional Cassava Dryer Machine

spin flash dryer cassava flour drying machine

The block state mate-rials will soon be smashed and contact the hot air fully and the materials are heated and dried. The dried materials after the dewatering will go up with the heat air flow. The step rings will stop and keep the big particles. Small particles will be discharged out of the drier from the ring center and will be restored by the whirl separator and dust remover. The not-fully-dried or big piece materials will be sent to the wall of the equipment by centrifugal force function and be smashed again after they fall down to the bottom.

Working Principle

Driven by the agitator to form a powerful rotating wind field. Paste material enters the dryer from the screw feeder. Under the strong action of the high-speed rotating stirring blade, the material is dispersed under the action of impact, friction and
shearing force. The block material is quickly crushed, fully contacted with hot air, and heated, dry.

Type	Barrel Diameter(MM)	Main Machine Dimensions (MM)	Main Machine Power (KW)	Treatment Wind Capacity (M/H)	Capacity(KG/H)	Occupied Area(M2)
GRT-XSL-2	200	250*2800	5-9	300-800	10-20	3500x2500
GRT-XSL-3	300	400*3300	8-15	600-2500	20-50	3800x2700
GRT-XSL-4	400	500*3500	10-17.5	1250-4000	25-70	4000x3000
GRT-XSL-5	500	600*4000	12-24	1500-4000	30-100	4200x3200
GRT-XSL-6	600	700*4200	20-29	2500-5000	40-200	4250x3250
GRT-XSL-8	800	900*4600	24-35	3000-8000	60-600	4500x3500
GRT-XSL-10	1000	1100*5000	40-62	5000-12500	100-1000	4750x3750
GRT-XSL-12	1200	1300*5200	50-89	10000-20000	150-1300	5000x4000
GRT-XSL-14	1400	1500*5400	60-105	14000-27000	200-1600	5250x4250
GRT-XSL-16	1600	1700*6000	70-135	18700-36000	250-2000	5500x4500

No	Item (XSG-10)	Data
1	moisture evaporation amount	400kg/h
2	inner diameter(mm)	1000
3	air volume(m³/h)	12000
4	Install power(kw)	75
5	Max height(m)	6.5
6	Occupied area(㎡)	45

1. Several feeding device can be chose, feeding is continuous andstable, no phenomenon of bridging.

2. There is special cooling device at the bottom of dryer, it canavoid the material that in the bottom high temperature area be bad.

3. There is special air sealing device and cooling device for bearing,it can make the life of transmission part longer effectively.

4. There is special air distributing device, it can reduce theresistance of equipment, and make the air speed in drying towerbecome balance.
5. There is classify ring and turbojet plate, the fineness and finalmoisture of product can be adjusted and controlled.6.Circumference air speed in the drying tower is high, theresidence time of material is short, it can avoid the material stick onthe wall and thermal sensitive materials go bad.

ISO9001 SUS304 Flour Drying Machine Multifunctional Cassava Dryer Machine 0

ISO9001 SUS304 Flour Drying Machine Multifunctional Cassava Dryer Machine 2
