Product Details
Place of Origin: Jiangsu, China
Brand Name: Shinma
Certification: ISO9001,ISO14001
Payment & Shipping Terms
Price: $30,000.00/sets 1-2 sets
Packaging Details: As per customer's requirement
Supply Ability: 20 Set/Sets per Year
Type: |
Belt Dryer |
Application: |
Medicine Processing, Chemicals Processing, Food Processing |
Condition: |
New |
Voltage: |
According To The Model |
Power: |
According To The Model |
Dimension(L*W*H): |
According To The Model |
Key Selling Points: |
Automatic |
Warranty: |
1 Year |
Weight (KG): |
14000 |
Applicable Industries: |
Manufacturing Plant, Food & Beverage Factory, Farms |
Showroom Location: |
None |
Marketing Type: |
Other |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Warranty Of Core Components: |
1 Year |
Core Components: |
Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine, Pressure Vessel |
Heating Method: |
Steam Heating |
Material: |
SUS304, SUS304L, SUS316, SUS316L, Other, All SUS304, SUS316L |
Heating: |
Steam, Oil, Electricity, Natural Gas |
After-sales Service Provided: |
Online Support, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training |
After Warranty Service: |
Video Technical Support, Online Support, Spare Parts |
Local Service Location: |
None |
Port: |
Shanghai |
Type: |
Belt Dryer |
Application: |
Medicine Processing, Chemicals Processing, Food Processing |
Condition: |
New |
Voltage: |
According To The Model |
Power: |
According To The Model |
Dimension(L*W*H): |
According To The Model |
Key Selling Points: |
Automatic |
Warranty: |
1 Year |
Weight (KG): |
14000 |
Applicable Industries: |
Manufacturing Plant, Food & Beverage Factory, Farms |
Showroom Location: |
None |
Marketing Type: |
Other |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Warranty Of Core Components: |
1 Year |
Core Components: |
Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine, Pressure Vessel |
Heating Method: |
Steam Heating |
Material: |
SUS304, SUS304L, SUS316, SUS316L, Other, All SUS304, SUS316L |
Heating: |
Steam, Oil, Electricity, Natural Gas |
After-sales Service Provided: |
Online Support, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training |
After Warranty Service: |
Video Technical Support, Online Support, Spare Parts |
Local Service Location: |
None |
Port: |
Shanghai |
WORKING PRINCIPLE
1. In the mesh belt dryer system, the following data can be a special set and adjusted in order to achieve the best drying effect: heating temperature, air flow, staying time.
2. Agility specified: we can add mesh belt washing system and product cooling system in mesh belt dryer system.
3.Agility operating: after conveying on mesh belt, wet material is dried in a totally sealed chamber during the whole drying process. Working condition is good because the system does not have powder leaking outside.
4. When wet material loaded in conveying belt, the relative position between every single material is quite stable. So for every single material, drying time is almost the same. This is especially suitable for drying that product that needs good color and uninformed water content. Additionally, during a drying process, the product will not be heavily shocked and vibrated, so granule size of granule will not break down. So this kind of mesh belt dryer is especially suit
|
No
|
Item
|
Data
|
|
1
|
moisture evaporation amount
|
400kg/h
|
|
2
|
operation temputure
|
50-140℃(designed as 90℃)
|
|
3
|
Initial water contentω1
Finial water contentω2 |
49%-54%(design as 54%)
≤3%(design as 3% )
|
|
4
|
Heating source
|
steam (0.6MPa)
|
|
5
|
Steam consume
|
450-1200kg/h
|
|
6
|
Equipment oversize
|
21560(L)*2320(W)*2500(H)
|
|
7
|
Power equipped
|
36.8kw
|
|
8
|
Total weight
|
Around 14 T
|
