220v 380v Conveyor Belt Dryer Apron Dryer 150kg/H To 375kg/H

Product Details

Place of Origin: Jiangsu, China

Brand Name: Shinma

Certification: ISO9001,ISO14001,CE

Payment & Shipping Terms

Price: $10,000.00 - $60,000.00/sets

Packaging Details: As per customer's requirement

Supply Ability: 25 Set/Sets per Year

Get Best Price
Highlight:

220v Conveyor Belt Dryer

,

380v Conveyor Belt Dryer

,

apron dryer 375kg/H

Type:
Dry Cabinet
Application:
Food Processing
Condition:
New
Voltage:
380v/220v
Power:
35
Dimension(L*W*H):
20X3X5
Key Selling Points:
Automatic
Warranty:
3 Years
Applicable Industries:
Food & Beverage Shops
Showroom Location:
None
Marketing Type:
Hot Product 2019
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
6 Months
Core Components:
PLC
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
After Warranty Service:
Online Support
Local Service Location:
None
Port:
Shanghai
Type:
Dry Cabinet
Application:
Food Processing
Condition:
New
Voltage:
380v/220v
Power:
35
Dimension(L*W*H):
20X3X5
Key Selling Points:
Automatic
Warranty:
3 Years
Applicable Industries:
Food & Beverage Shops
Showroom Location:
None
Marketing Type:
Hot Product 2019
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
6 Months
Core Components:
PLC
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
After Warranty Service:
Online Support
Local Service Location:
None
Port:
Shanghai
220v 380v Conveyor Belt Dryer Apron Dryer 150kg/H To 375kg/H

DW Apron conveyor mesh belt dryer/Apron dryer

Description of DW Apron conveyor mesh belt dryer/Apron dryer

Material to be dried:

Dehydration vegetables, grain feed, monosodium glutamate, shredded coconut stuffing, organic pigments, synthetic rubber, acrylic fiber, medicines, medicinal herbs, wooden products, plastic products, electronic components aging, curing and so on.



Application Range:

Fruit & Vegetable Mesh-belt dryer is used for mass production of continuous drying equipment for the drying of sheet, strip pellet material with better ventilation property, especially for the materials cannot bear high temperature such as dehydrated vegetables, Chinese herbal pieces of high moisture content. Belt driers have many advantages, such as fast drying rate, high evaporation strength, good product quality; cake type of paste materials, wet granulation can also be dried.



Application of DW Apron conveyor mesh belt dryer/Apron dryer

The belt dryer is an ordinary continuous drying equipment. It is widely used for chemical industry, foodstuff industry, pharmaceutical industry, construction materials industry, electronic industry and so on. Especially it is suitable for drying raw materials that are good in breathability and have the shape of pieces or strip of granule. It is also possible to dry the pasted raw materials such as filter cake after shaped through granulator or extruder.





Technical parameters

Type

DW-1.2-8

DW-1.2-10

DW-1.6-8

DW-1.6-10

DW-2-8

DW-2-10

DW-2-20

Quantity of unit

4

5

4

5

4

5

10

Belt width(m)

1.2

1.6

2

Length of drying section(m)

8

10

8

10

8

10

20

Thickness of raw material(mm)

≤60

Operation temperature(°C)

50-140

Steam pressure(MPa)

0.2-0.8

Steam consume(kg/h)

120-300

150-375

150-375

170-470

180-500

225-600

450-1200

Drying time(h)

0.2-1.2

0.25-1.5

0.2-1.2

0.25-1.5

0.2-1.2

0.25-1.5

0.5-3

Drying strength(kg/h)

60-160

80-220

75-220

95-250

100-260

120-300

240-600

Power equipped(kw)

11.4

13.6

11.4

13.6

14.7

15.8

36.8

Overall dimensions

L(m)

9.56

11.56

9.56

11.56

9.56

11.56

21.56

W(m)

1.49

1.49

1.9

1.9

2.32

2.32

2.32

H(m)

2.3

2.3

2.4

2.4

2.5

2.5

2.5

weight(kg)

4500

5600

5300

6400

6200

7500

14000
